W2023 PID Temperature Controller (220 V)

0104110000055613

New product

Main Performance

  • NTC measurement input (B3950/10K T=25" 10KR)
  • PID self-tuning function; it can automatically adapt to various control objects
  • AC 220V low voltage power supply, safer for high-end precision occasions
  • Direct solid-state output, no mechanical action, quieter and longer life


See description for more details about the product.

Add to cart now!

More details

6 Items

$35.76
tax incl.

Valid in the limit of the available stock

The price includes the costs for collection, treatment and ellimination of WEEE

Add to wishlist

More info

Technical Data

• Control range: -55 ~ 120 oC

• Temperature control accuracy: +/- 0.1 - 0.2 oC

• Refresh rate: 4 times/sec

• Input voltage: AC 220V 50Hz

• Output current: MAX 15A

• Maximum power: 2200W

• Display size: 0.56 inch

• Size: 75x35x85 mm


Instructions for use

  1. Connect the power supply to the input terminal and the heating device to the output.
  2. The screen will display the real-time temperature after powering on. Press SET once to set the desired temperature and press RST to confirm.
  3. Long press RST can power off the controller without pulling the cable off the switch. Settings are automatically saved.
  4. Press and hold the SET button in order to enter in the internal settings


Internal settings menu

Code Description Setting range Default value
P0 Self-tunning switch on/off off
P1 PID response speed 1 - 3 1
P2 Proportional gain 0.1 - 9.99 0.2
P3 Integration time 1 - 999 200
P4 Differential time 1 - 999 20
P5 Working period 2 - 60S 5
P6 High-temperature alarm - 50 ~ 120 oC off

Schematics


Don't delay, buy today.


Add to cart now!

Reviews

Grade
11/15/2021

W2023

La varianta 230V iesirea PID pe triac este adecvata comenzii unei vane motorizate. Ar fi util de mentionat in prezentarea caracteristicilor

  • 1 out of 1 people found this review useful.
