Neodymium Disc Magnet 2x10 Thick N38H

0104210000066135

New product

Neodymium Disc Magnet 2x10 Thick N38H


See description for more details about the product.

Add to cart now!

More details

This product is no longer in stock

$0.06
tax incl.

Valid in the limit of the available stock

The price includes the costs for collection, treatment and ellimination of WEEE

-$0.18

$0.24 tax incl.

Add to wishlist

More info

Magnet parameters:

• diameter: 2 mm (±0.1 mm)

• height: 10 mm (±0.1 mm)

• weight of the magnet: ~0.24 g

• material: Neodym NdFeB

• direction of magnetisation: axial, along the height

• max. working temperature: 120oC.

• coating: Ni + Cu + Ni

• strength: ~0.15 kg

Magnetic properties of N38H material:

• remanence Br: 1.22-1.25 [T]; 12.2-12.5 [kGs]

• coercivity Hcb: ≥899 [kA/m]; ≥11.3[kOe]

• coercivity HcJ: ≥1353 [kA/m]; ≥17 [kOe]

• energy density (BH) max: ≥287-310 [kJ/m3]; 36-39 [MGOe]
