ULN2003 Stepper Driver + 5V Stepper Motor
0104110000008091
New product
This product contains a 5 V stepper motor and a stepper motor driver module based on the ULN2003A Darlington transistor array.
See description for more details about the product.
Add to cart now!
565 Items
- Remove this product from my favorite's list.
- Add this product to my list of favorites.
More info
Description
This product contains a 5 V stepper motor and a stepper motor driver module based on the ULN2003A Darlington transistor array.
The driver is based on a ULN2003 integrated circuit that contains several Darlington configurations. It works at very good parameters along with the stepper motor in the kit.
Step-by-step motors are often used in applications requiring precise motion control. You can meet them in 3D printers or normal printers, CNCs or robotic arms. In order to choose the right stepper for your application, see the data sheet to see the power consumption, engine speed and accuracy, torque and how to control it.
Specifications
- Recommended power voltage: 5V
- Number of phases: 4
- Approximate reduction: 1:64
- 64 steps / resolution
- Resistance / phase: 50 ohms
- Minimum torque: 34.3 mN * m
- Degree of insulation: A
Don't delay, buy today.
Add to cart now!
Reviews
Buna
Se poate folosi la 220
- 0 out of 12 people found this review useful.
mic si puternic
destul de fortos, o sa mai iau inca unul la fel si o sa le modific din unipolar in bipolar (e un castig de aproximativ 500g/cm, de la 350g/cm la 800g/cm). poate ajuta pe cineva ceva info despre versiunile de motorase https://grahamwideman.wikispaces.com/Motors-+28BYJ-48+Stepper+motor+notes
- 19 out of 19 people found this review useful.
Ar fi super sa aduceti motoare 28BYJ-48
Asemenea motoare am testat pe un solar-tracker si pot fi extrem de lente si de precise.
- 13 out of 14 people found this review useful.
