0.36" 4 Digit LED Display Common Anode

0104110000003607

New product

4-digit red LED display with common anode.


See description for more details about the product.

Add to cart now!

More details

563 Items

3,46 lei
tax incl.

Valid in the limit of the available stock

The price includes the costs for collection, treatment and ellimination of WEEE

Add to wishlist

More info

Technical specifications

  • LED voltage drop: 2 V - 2.2 V
  • Recommended voltage drop on LED: 2.1 V
  • Current Current: 20 mA
  • Wavelength: 640 nm
  • Operating temperature: -25oC to + 85oC
  • Light intensity: 55 mcd
  • Dimensions: 30 mm x 14 mm x 7.2 mm


The 4-digit red LED display module, each with 7 segments, is useful in electronic assemblies where numbers must be displayed. Being 4 digits is useful for displaying time or timer.

The module has a common connection for each digit of the LED anode.

The pinout is 12 pins, two rows of 6 pins, and is represented by the parallel cathodes of the leds and the four common anodes.


Don't delay, buy today.


Add to cart now!

Reviews

Grade
05/01/2017

afisaj led

Calitate foarte buna si consum mic de curent

  • 3 out of 3 people found this review useful.

Write your review!

Write a review

0.36" 4 Digit LED Display Common Anode

0.36" 4 Digit LED Display Common Anode

4-digit red LED display with common anode.


See description for more details about the product.

Add to cart now!

Customers who bought this product also bought:

Download

Pinout display 4 digit A

Download (14.05k)

Pinout display 4 digit

Download (19.44k)
