APDS-9930 Gesture Sensor

Overview

This APDS-9930 gesture sensor provides ambient light sensor and proximity sensor integrated into a small module. It provides I2C interface-compatible Ambient Light Sensor (ALS) and proximity sensor in one 8-pin package. The ALS uses a dual photodiode to approximate illumination of 0.01 lux.

The proximity sensor is capable of detecting objects at a distance of up to 100 mm. It works perfectly both in sunlight and in dark rooms. It has micro-optic lenses to provide efficient transmission and reception of infrared energy.

Specifications

• Ambient light sensor and proximity sensor integrated
• Up to 16-bit resolution
• High sensitivity (even in the dark)
• Lumen performance at 0.01 lux
• Factory calibrated sensor
• Low-power current consumption: 90 μA
• I2C compatible (up to 400 KHz, fast mode)
• Dedicated interrupt pin
• Sleep mode: 2.2 μA
• Dimensions: 3.94 x 2.36 x 1.35mm
